Removable hard drive tray for 2.5' SATA drive. The Cloud Key G2 Plus only supports hard drives that can operate on 5V power. Hard drives that require additional power are not supported.

Device Status display. Automatically rotates status screens for enabled controllers.

UniFi Network Display

UniFi Protect Display

LCD Display for UniFi Network

LCD Display for UniFi Protect

Press to turn the Cloud Key Gen 2 Plus on or off.

The Reset button serves two functions:

• Restart Press and release the Reset button quickly.
• Restore to Factory Default Settings Press and hold the Reset button for more than five seconds, until the status LED begins flashing white.

Optional slot used for external backup (microSD card not included).

Reserved for future use.

Used for power if PoE is not available. Quick Charge 2.0 or Quick Charge 3.0-compliant USB power adapter is required.

Connects to a gigabit switch port on your LAN. Power can be provided by an 802.3af PoE switch, such as the UniFi PoE Switch.

White

Device is ready to be configured

Flashing White

Device is booting up

Device is initializing/deinitializing

Heartbeat White

Firmware update in process

Blue

Device is configured and ready

Flashing Blue

Main power has been lost and device is counting down.

If power is restored within 10 seconds, the device will return to its previous state. If power is not restored within 10 seconds, the device will safely shutdown.

Slow Flashing Blue

Client connected to device via Bluetooth (BLE)

Flashing White/Blue

Device is in recovery mode.

The LED will cycle through a pattern at one-second intervals, between off, white, and blue.

Allows the Cloud Key Gen 2 Plus to be used with a Kensington security lock (not included). When used, it also prevents removal of the HDD while the device is in use.

Secures the Cloud Key Gen2 Plus into the docking bay of the optional Rackmount Accessory, model CKG2-RM (sold separately). The Rackmount Accessory allows you to install the Cloud Key Gen2 Plus in a standard 19' rack.

Connects the Cloud Key Gen2 Plus to the optional Rackmount Accessory, model CKG2-RM (sold separately). The CKG2-RM has a docking bay for the Cloud Key Gen2 Plus and allows you to install it in a standard 19' rack.

Releases the HDD tray from the drive bay.Releases the HDD tray from the drive bay.

Warning: To prevent creating a loop or other unfavorable behavior on the network, only one Ethernet connection should be used. Do not use the Ethernet port on the Cloud Key Gen2 Plus and the Rackmount Accessory simultaneously.

Note: Ensure that Bluetooth is enabled on your mobile device. You will need to set up the Cloud Key Gen2 Plus with your mobile device and be within 1.5 m (5') from where it is installed.

Note: You can run the UniFi Network Controller or UniFi Protect software individually, or you can run both applications simultaneously.

The Dashboard screen provides a visual overview of your network’s status, including latency and throughput information for each client and device.

The Statistics screen provides a visual representation of the clients and network traffic on your managed UniFi Network network.

The Map section allows you to create maps (either upload custom images of your location(s) or use Google Maps™) for a visual representation of your Network network and also view your system topology.

The Devices screen displays a list of UniFi devices managed by your Network controller.

The Clients screen displays a list of clients connected to UniFi devices managed by your Network controller.

The Insights screen lists detailed information about local and surrounding wireless networks, client and device statistics, security and connection detail, and other controller access information.

The Release Notes window provides information and details on the incorporated changes and/or updates to the latest UniFi Network controller software.

The Events screen provides a list of all events and activity taking place on your network, including errors and warnings.

The Alerts window provides a list of alerts and events occurring on your network.

The Settings screen provides detailed information about your UniFi Network controller and allows you to add/change/update the site configuration.

The Live Chat Support screen provides access to a UniFi professional support representative available via live chat 24/7.

The Cameras screen lists all cameras currently managed by UniFi Protect.

The Live View screen lists all live view layouts for UniFi Protect. Click Add Live View to create a new live view.

Review events recorded by UniFi Protect. Customize your events by selecting a camera from the drop-down list and creating a specific date range of recordings to view. You can also choose a date range from one of the
pre-defined shortcuts in the upper-right menu.

Add/change/delete users in UniFi Protect.

View/update/reset the system configuration of UniFi Protect.

Note: The Cloud Key G2 Plus only supports hard drives that can operate on 5V power. Hard drives that require additional power are not supported.

131.16 x 27.10 x 134.20 mm
(5.16 x 1.07 x 5.28')

582 g (1.28 lb)

Anodized Aluminum

UniFi Management Portal;
UniFi Network; UniFi Protect

1 TB 2.5' SATA HDD
(user-upgradeable*)

32 GB

(1) 10/100/1000 Ethernet Port

(1) Power

(1) Reset

(1) Power, White/Blue

Standard 802.3af PoE;
Quick Charge 2.0/3.0 power adapter (9VDC, 2A)

Standard 802.3af PoE or
9VDC, 2A

12.95W (PoE)
USB-C Power

0 to 35° C
(32 to 104° F)

20 to 80% Noncondensing

CE, FCC, IC
